Traxxas Stampede 4X4 VXL Brushless RTR Monster Truck w/TSM & TQi Blue

This is the Traxxas Stampede 4X4 Brushless VXL Ready-to-Run Waterproof Radio Controlled Monster Truck with Traxxas Stability Management (TSM), Self Righting, and the TQi 2.4GHz Radio System (Traxxas Bluetooth Link Module Compatible – Module sold separately). Battery and charger are sold separately.

Traxxas Stability Management

Traxxas Stability Management (TSM) allows you to experience all the extreme power, speed, and acceleration that was engineered into the Stampede 4X4 VXL by making it much easier to control on common slippery surfaces such as loose dirt, smooth concrete, and even ice and snow. Punch it off the line and TSM goes to work sensing the vehicle’s direction and making steering corrections to provide straight-ahead full-throttle acceleration without fishtailing, spinouts, and loss of control. TSM also works during cornering, first making intuitive corrections to maintain your line, and then allowing you to hammer the throttle earlier in the turn for much faster exit speeds. Braking is dramatically improved as TSM works to keep you arrow straight until you come to a complete stop. TSM acts as your on-board co-pilot in the vehicle that “feels” what the vehicle is doing and makes corrections for vehicle movements that you cannot even detect, well before the vehicle gets out of control.

Traxxas TSM gives you all the benefits modern electronic stabilization has to offer without intruding on your driving fun. Traxxas engineers developed superior tuning algorithms that run on high-speed, precision electronic components to create a system that works invisibly, in the background, without ever limiting your throttle. TSM can be fine tuned (or turned off) for different surfaces by simply adjusting the multi-function knob on the TQi transmitter, or by adjusting the slider in the Traxxas link app. The result is that you are driving faster, with more ease, and having more fun,with that fully connected feeling at the controls that you expect. In fact, you may not even realize how much TSM is helping you until you turn it off and test your driving skills without it!

TSM Benefits

• TSM makes Traxxas vehicles easier to drive, particularly on loose surfaces
• TSM makes driving more fun by allowing the driver to accelerate harder and drive faster with much greater control
• TSM works to stabilize vehicles over rough surfaces as the gyro effect of the spinning front tires continues to “steer” when the vehicle is in the air
• TSM dramatically improves braking performance, preventing the vehicle from spinning out
• TSM allows faster cornering speeds
• TSM never restricts throttle (or fun!)
• TSM allows the driver to accelerate harder when exiting a turn
• TSM works invisibly in the background
• The driver maintains their connected feel with the vehicle
• The amount of TSM assistance is fully adjustable
• TSM can be turned off or adjusted from the TQi Transmitter
• TSM is fully compatible with Traxxas Link
• TSM does not require any complicated set up or instructions

Self-Righting
The Traxxas exclusive Self-Righting feature made its debut in the ground-breaking X-Maxx monster truck. But we didn’t limit this innovation to one truck. With one press of a button, your monster truck can automatically get itself back on all four tires. This means the action doesn’t have to stop to rescue an upside down truck.
The World’s Most Advanced Ready-To-Race Radio System
Stampede 4X4 is equipped with the world’s most advanced Ready-To-Race radio system. The all-new Traxxas TQi arrives with a full complement of tuning features and offers the unbeatable convenience of “no channels, no crystals” 2.4GHz technology – but that’s just the beginning. Automatic model recognition instantly recalls your settings for up to 30 Traxxas Link-enabled models. Just switch on and drive, no naming or “model memory” settings required. Power up the transmitter and the model you want to drive, and the settings for that model are dialed in immediately! The new TQi 2.4GHz transmitter is fully adjustable: steering and throttle end points can be set precisely, and the Multi-Function knob can be programmed to control Steering Sensitivity (Expo), Throttle Sensitivity (Expo), Steering Percentage (Dual Rate), Braking Percentage (Dual Rate), or Throttle Trim. TQi’s ergonomic case design provides all-day driving comfort, and the unique internal antenna contributes to its sleek, modern look.

Traxxas Link Wireless Module Compatible
The TQi’s most important new feature may already be in your pocket. The TQi can be equipped with an Traxxas Link Wireless Module (#6511, sold separately) that turns your iPad, iPhone, or iPod touch (sold separately) into a powerful tuning tool for your Traxxas model. The full-color display combines with the free Traxxas Link App (on the App Store) to deliver an intuitive, high-definition, full-color graphical user interface that unlocks the mysteries of optimizing your radio system for ultimate vehicle control. Traxxas Link also opens the door to telemetry capability when you add optional sensors to your model.

Features

• NEW Traxxas Stability Management
• Powered by the Velineon Brushless Power System
• Stampede 4X4 VXL reaches speeds in excess of 60mph!**
• Traxxas High-Current ID Connector (patented) allows high-capacity battery packs to deliver maximum voltage to the Velineon Brushless Power System
• Exclusive waterproof electronics extend brushless power and performance to water, mud, and snow
• Maxx Cable 12-gauge wire
• Velineon VXL-3s Electronic Speed Control
  • LiPo, NiCad, and NiMH compatible with two-stage low-voltage detection
  • Sport Mode – Forward / Brake / Reverse
  • Race Mode – Forward / Brake
  • Training Mode – 50% Forward / Brake / 50% Reverse (patented)

• Velineon 3500 Brushless Motor
  • Consistent, high-power output, run after run
  • Low-maintenance, unique Traxxas design
  • Efficient, high-speed ball bearings
  • Precision-balanced rotor

• NEW TQi 2.4GHz transmitter
  • Compatible with optional TQi Traxxas Link Wireless Module (#6511) to access full Traxxas Link app functionality
  • Automatically stores and loads settings for up to 30 Traxxas Link-enabled models – just switch on and drive, “model selection” is not required
  • Multi-Function knob
  • Adjustable steering and throttle percentage (dual rates)
  • Adjustable steering and throttle sensitivity (exponential)
  • Adjustable steering and throttle end points
  • High 13ms frame rate and near-zero latency for responsive control
  • TQi 2.4GHz TSM Receiver

• Heavy-duty 4mm steel turnbuckles and captured rod ends
• Single-screw motor access makes gear-mesh adjustments fast and easy and the motor can be removed in just seconds
• Modular simplicity, fiber-composite monocoque chassis
• Speed control and receiver are securely fastened to chassis
• Integrated Personal Transponder Mount
• Digital high-torque Traxxas #2075 waterproof steering servo
• Waterproof, o-ring sealed receiver box
• Sealed, silicone-filled differentials
• Revo-Spec Torque-Control slipper clutch system
• Fully adjustable oil-filled Ultra Shocks with X-ring technology
• White powder coated shock springs feature a responsive spring rate
• Telescoping universal-joint driveshafts
• Rubber-sealed ball bearings
• Black-chrome All-Star 2.8″ wheels
• Talon multi-terrain tires with high-performance foam inserts
• ProGraphix painted body
• Full line of genuine Traxxas accessories available
• Stampede 4X4 VXL is backed by unparalleled Traxxas support and parts availability

Powered by Passion
We take our monster trucks seriously at Traxxas, and the all-new Stampede 4X4 VXL is engineered like no other to turn extreme power into extreme monster truck fun! The efficient, low-mass drivetrain is totally optimized for the brutal torque of Velineon brushless power, and following the legacy of the Stampede name, this 4X4 is overbuilt and Traxxas Tough to withstand all the 4-wheel drive monster mayhem you can dish out. The patented adjustable wheelie bar is required equipment as Stampede 4X4 launches hard, sending the front wheels soaring for the sky. You’re in full control with the new Traxxas TQi 2.4GHz radio system and the superior handling of fully independent suspension and smooth bellcrank steering. The Velineon Brushless Power System gets the Stampede 4×4 VXL 35+mph using an 8.4V NiMH or install a 3S LiPo pack, and Stampede 4X4 shatters the speedometer with 60+mph speed! It’s brushless done the Traxxas way: brutally fast and easy to use. Just plug it in and switch it on to feed your need for extreme horsepower.

All-New Chassis Optimized for Monster Fun
Stampede 4X4 is built on the proven performance of the advanced shaft-driven 4WD system and innovative modular design of the award-winning Slash 4X4. The new chassis fully integrates the electronics and battery compartment for an efficient and compact layout, and maintains the high center ground clearance that gives Stampede its monster stance and high-riding look. The extra clearance drastically increases the offroad versatility that allows you to tackle rougher terrain and bigger obstacles. The Stampede 4X4 feels planted and secure at speed, even on pavement and in other high-grip conditions. Stampede 4X4 is 100% monster truck, but it handles like a racing machine!

Proven Velineon Brushless Power
Stampede 4X4’s Traxxas Velineon Brushless Power system defines a new generation of outrageous electric power that doesn’t know limitations and boundaries. Pour in the voltage and out comes the speed in tidal waves of force harnessed by precision throttle control. For the uninitiated, prepare yourself… the sheer brutal power combined with the Stampede 4X4’s four-corner grip results in tire-melting acceleration and lightning fast speed. The Velineon 3s Brushless Power System features system components that work together as an optimized package, from the patented Traxxas High-Current connector to the custom-wound motor. It’s engineered together from the start to deliver the ultimate in efficiency, speed, and run-time along with precision throttle response and refined control. It’s brushless performance the Traxxas way: wicked fast and easy to use. Just plug it in and it works, no special knowledge or programming skills required.

Ultra Efficient Shaft-Driven 4WD
Stampede 4X4 uses just three gear meshes to drive all four wheels, eliminating the need for a multi-gear transmission. The highly efficient drivetrain spins effortlessly on rubber-sealed ball bearings, and is integrated seamlessly into the unique chassis for optimum performance and easy maintenance. The center driveshaft is formed from extruded aluminum. There are no dogbones to wear, no drive cups to wobble. The extrusion process allows the shaft to be hollow and lightweight with internal splines that fit directly and securely onto the input shafts of the front and rear drive assemblies. The shaft runs perfectly straight and true and offers superior durability. Traxxas engineers highlighted this important innovation with vivid blue anodizing and a laser-etched Traxxas logo. A clear cover shows off the high-tech look while keeping dirt and debris away from the shaft.

Sealed Electronics Extend Your Driving Fun
Only Traxxas lets you experience brushless-powered 4WD excitement year-round, no matter what mother nature has to offer. Water, mud, and snow don’t slow down Stampede 4X4; its electronic speed control, receiver box, and high-torque digital steering servo are all waterproof for no-worry fun in wet conditions that send other trucks running for cover. Drive Stampede 4X4 where you want, when you want – the only limit is your imagination.

100% Fully Assembled and Ready-To-Race
Stampede 4X4 comes fully-assembled and Ready-To-Race with the TQi 2.4GHz radio system installed and adjusted, Velineon brushless power system, a painted and decaled body, pre-glued tires, and detailed instructions. Traxxas backs Stampede 4X4 and all of their products with top-notch support that is second to none. A staff of skilled representatives is on-hand to answer your questions via phone, website, or e-mail. Unmatched parts support allows Stampede 4X4 to be serviced with parts and support from thousands of hobby dealers worldwide. Your investment is also protected by the Traxxas Lifetime Electronics Warranty. Traxxas goes the extra mile to ensure that your R/C experience is easy and fun (and fast!).

Specifications

Length: ­ 19.69 Inches (500mm) / 15.63 Inches (397mm) without wheelie bar
Front Track: ­ 13.39 Inches (340mm)
Rear Track: ­ 13.39 Inches (340mm)
Center Ground Clearance: ­ 2.90 Inches (74mm)
Weight: ­ 66.45oz (1.88kg)
Height (overall): ­ 9.21 Inches (234mm)
Wheelbase: ­ 10.83 Inches (275mm)
Shock Length: ­ Long (front), XXLong (rear)
Tires: ­ Talon 2.8″
Tire Diameter: ­ 4.80 Inches (122mm) (front and rear)
Wheels (front/rear): ­ 2.8″ Black-Chrome (All-Star)
Wheel Diameter: ­ 2.8 Inches (72mm) Outer
2.8 Inches (72mm) Inner
Speed Control Type: ­ VXL-3s Electronic Speed Control
Motor (electric): ­ Velineon 3500 Brushless
Overall Drive Ratio: ­ 13.97 (stock, out-of-box)
Differential Type: ­ Hardened Steel Bevel, Sealed, Limited Slip
Gear Pitch: ­ 32
Chassis Structure/Material: ­ Molded Tub / Nylon Composite
Drive System: ­ Shaft-Driven, Direct Drive 4WD
Steering: ­ Dual-Bellcrank with Integrated Servo Saver
Radio System: ­ TQi 2.4GHz (2-channel)
Body: ­ ProGraphix, Traxxas Stampede
Top Speed: ­ 60+mph**
Skill Level: ­ 1
Battery Tray Dimensions*: ­ 142mm x 48.5mm x 23mm, 25mm

Requires:

4 “AA” Batteries (for transmitter)
Battery – 8.4V NiMH hump pack or 2S-3S LiPo

*Battery expansion kit available (Traxxas #6727X).
**With optional gearing and 3S LiPo battery (items sold separately).
